3000W 58V 60A High Power Wireless Charger

The LS300-A60 Wireless Charging System consists of a Transmitting Controller, Transmitting Coil, Receiving Controller, and Receiving Coil, delivering a maximum output power of 3000W. This system is designed to wirelessly charge devices equipped with lithium batteries and lithium iron phosphate batteries.

Compared to traditional contact-based charging methods, this wireless charging solution offers significant advantages including enhanced safety and zero maintenance requirements. The system is ideally suited for mobile robotic applications such as AGVs (Automated Guided Vehicles), AMRs (Autonomous Mobile Robots), and unmanned forklift trucks.

Basic Parameters

• Output power: 3kW Max
• Transfer efficiency: 90% Max (at optimum distance)
• Wireless charging distance: 20-45mm
• Operating frequency: 85kHz
• Communication method (Transmitter and receiver ) : 2.4G
• Communication protocol: CAN / RS485
• Magnetic insulation protection: Magnetic material + aluminum plate shield
• Startup: Automatic detection self-starting
• Charging method: constant current and constant voltage

Transmitter Parameters

• Input voltage: 1-phase 200-240V, 50/60Hz
• Input current: 16A Max
• Transmitter controller Dimension: L*W*H=460*378*110mm
• Transmitter controller Weight: Approx. 7.5kg
• Transmitter controller housing material and IP grade: Aluminum plate, IP20
• AC input: C20 socket (1.8m three-plug cable is optional)
• Transmitter coil size: L*W*H=295*295*20mm
• Transmitter coil weight: Approx. 5.85kg (including 8m cable)
• Transmitter coil outlet cable length: 3m (wire diameter about 6mm, Φ18mm bellows wrapped)
• Transmitter coil housing material and IP grade: ABS+PC and aluminum alloy, IP65 (filling glue), maximum bearing capacity 1.2 tons

Receiver Parameters

• Output rated voltage: 58V (applicable range: 42-58V)
• Output rated current: 60A Max. (Adaptable range: 10-60A)
• Output voltage ripple: About ±3.5%
• Output current ripple: About ±3.5%
• Type of load: Lithium battery
• Receiver coil size: L*W*H=233*233*26mm
• Receiver coil weight: Approx. 5.7kg (including adapter structure)
• Receiver coil outlet length: Approx. 1m (wire diameter approx. 10mm, Φ25mm bellows wrapped)
• Receiver coil housing material and IP grade: PC and aluminum alloy, IP65 (filling glue), maximum bearing capacity 0.5 tons
• Receiver controller Dimension: L*W*H=150*150*75mm
• Receiver controller Weight: About 1.2kg
• Length of the DC output cable: Approx. 1m, wire diameter approx. 8.5mm (optional 120A Anderson connector)
• Receive controller shell material and IP grade: Aluminum plate, IP54

Other Auxiliary Power And Signal Data

• No need for external power supply and boot signal
• Receiver end auxiliary source output voltage: 12V DC (non-isolated, 12V- connected to DC-, not recommended for customers)
• Receiver end auxiliary source output current: 0.1A Max
• Transmitter end auxiliary source output voltage: 12V DC
• Transmitter end auxiliary source output current: 0.1A Max
• Communication signals at transmitter end: 485 / CAN
• Communication signals at the receiver end: 485 / CAN

Other Certifications

• EMC: EN 300 440, EN 301 489-1/-3, EN 62311, EN 55011
• Safety: EN 62477-1:2012/A12:2021, UL 1564, CSA C22.2 No. 107.2-01
• Immunity: EN 61000-6-2
• FCC: FCC Part 15, FCC Part 18
• Chemistry: Reach
• Protection class: Transmitter controller =1, Transmitter coil =2, Receiver controller =2, Receiver coil =2

Protection Features

• Protection features: Overload, over temperature, over current, short circuit, over voltage, etc.
• Special attention: The output cannot be reversed

Lead time

We keep them in stock. Contact us for lead time. If they're in stock, we can ship out within one week. If they're out of stock, lead time is 30 days maximum. Contact us to learn more at info@onepointech.com.

Bulk order

We provide tiered pricing for bulk purchases.
For a custom quote, please contact us with your quantity requirements.
